High Conversion Efficiency
Advanced TOPCon bifacial cells deliver superior energy yield Maximizing power output under diverse operating conditions
High Efficiency: Up to 23.0% module efficiency
Bifacial Design: Dual-sided power generation for higher yield
Durable Build: Double-glass structure with corrosion-resistant frame
Low-Light Performance: Reliable output under weak or diffused light
Long-Term Reliability: 12-year product warranty & 30-year linear power warranty
Brand:
NUUKOItem NO.:
NKM430-450N-108BDM10
Product Advantages
Advanced TOPCon bifacial cells deliver superior energy yield Maximizing power output under diverse operating conditions
Stable energy generation in low-irradiance and diffuse light conditions Ensures consistent daily energy harvest across all weather
Double-glass structure with enhanced mechanical strength and sealing integrity Designed for long-term operation in harsh environments
Minimized power loss through Anti-PID and Anti-LID technologies Ensures stable long-term performance and sustained energy yield
Optimized module design ensures broad application adaptability Suitable for residential, commercial, and utility-scale PV systems
Product Specifications
| Cell Type | N type Mono-crystalline |
| Cell Arrangement | 108 (6*18) |
| Weight | 24.5KG |
| Module Dimensions | 1722*1134*30mm |
| Cable Length | 4.0mm², ±300mm or Customized length |
| Front Glass | 2.0mm,Anti-Reflection Coating |
| Back Glass | 2.0mm, Heat Strengthened Glass |
| No.of Bypass Diodes | 3/6 |
| Packing Configuration | 36pcs/pallet,936pcs/40HQ |
| Frame | Anodized Aluminium Alloy |
| Junction Box | IP68 |
| Module Type | NKM430N-108BDM10 | NKM435N-108BDM10 | NKM440N-108BDM10 | NKM445N-108BDM10 | NKM450N-108BDM10 | |||||
| Testing Condition | STC | NMOT | STC | NMOT | STC | NMOT | STC | NMOT | STC | NMOT |
| Rated output (Pmp/Wp) | 430 | 326 | 435 | 330 | 440 | 334 | 445 | 339 | 450 | 343 |
| Maximum Power Voltage(Vmpp/V) | 32.3 | 30.3 | 32.5 | 30.5 | 32.7 | 30.7 | 32.9 | 30.9 | 33.1 | 31.1 |
| Maximum Power Current(Impp/A) | 13.31 | 10.74 | 13.38 | 10.82 | 13.46 | 10.89 | 13.53 | 10.96 | 13.6 | 11.03 |
| Open Circuit Voltage(Voc/V) | 38.3 | 36.6 | 38.4 | 36.8 | 38.6 | 37.0 | 38.8 | 37.2 | 39.0 | 37.4 |
| Short Circuit Current(Isc/A) | 14.12 | 11.38 | 14.18 | 11.43 | 14.25 | 11.48 | 14.32 | 11.53 | 14.39 | 11.58 |
| Module efficiency(%) | 22.0% | 22.3% | 22.5% | 22.8% | 23.0% | |||||
| Power Tolerance (W) | 0~+5 | 0~+5 | 0~+5 | 0~+5 | 0~+5 | |||||
| Pmax/W | 462 | 484 | 506 | 528 | 550 |
| Vmpp/V | 32.7 | 32.7 | 32.7 | 32.7 | 32.7 |
| Impp/A | 14.13 | 14.80 | 15.48 | 16.15 | 16.83 |
| Voc/V | 38.6 | 38.6 | 38.6 | 38.6 | 38.6 |
| Isc/A | 14.96 | 15.68 | 16.39 | 17.10 | 17.81 |
| Pmax gain | 5% | 10% | 15% | 20% | 25% |
| Maximum System Voltage | 1500V DC（IEC） |
| Operating Temperature | -40°C ~+85°C |
| Maximun Series Fuse | 30A |
| Static Loading | Snow Loading：5400Pa / Wind Loading：2400Pa |
| Protection Class | II |
| Fire Type | Class C (IEC) |
| Bifacial | 80±5% |
| NMOT Temperature | 45℃±2℃ |
| Temprature Coefficient (Pmax) | -0.29%/℃ |
| Temprature Coefficient (Voc) | -0.25%/℃ |
| Temprature Coefficient (Voc) | 0.045%/℃ |
Product Certification
