535W-555W N-Type TOPCon Bifacial Double-Glass Solar Module

High Efficiency: Up to 23.4% module efficiency

Bifacial Design: Dual-sided power generation for higher yield

Durable Build: Double-glass structure with corrosion-resistant frame

Low-Light Performance: Reliable output under weak or diffused light

Long-Term Reliability: 12-year product warranty & 30-year linear power warranty

Brand:
NUUKO
Item NO.:
NKM535-555N-132BDM10

Product Advantages

Core Advantage

High Conversion Efficiency

Advanced TOPCon bifacial cells deliver superior energy yield Maximizing power output under diverse operating conditions

High Energy Capture Capability

Stable energy generation in low-irradiance and diffuse light conditions Ensures consistent daily energy harvest across all weather

Superior Durability

Double-glass structure with enhanced mechanical strength and sealing integrity Designed for long-term operation in harsh environments

Advanced Degradation Control

Minimized power loss through Anti-PID and Anti-LID technologies Ensures stable long-term performance and sustained energy yield

Universal Application Scenarios

Optimized module design ensures broad application adaptability Suitable for residential, commercial, and utility-scale PV systems

Product Specifications

Mechanical Specifications
Electrical Specifications
Maximum Ratings

Cell Type	N type Mono-crystalline
Cell Arrangement	132 (6*22)
Weight	30KG
Module Dimensions	2094113430mm
Cable Length	4.0mm², ±300mm or Customized length
Front Glass	2.0mm,Anti-Reflection Coating
Back Glass	2.0mm, Heat Strengthened Glass
No.of Bypass Diodes	3/6
Packing Configuration	36pcs/pallet, 792pcs/40HQ
Frame	Anodized Aluminium Alloy
Junction Box	IP68

Module Type	NKM535N-132BDM10		NKM540N-132BDM10		NKM545N-132BDM10		NKM550N-132BDM10		NKM555N-132BDM10
Testing Condition	STC	NMOT	STC	NMOT	STC	NMOT	STC	NMOT	STC	NMOT
Rated output (Pmp/Wp)	535	404	540	408	545	412	550	415	555	419
Maximum Power Voltage(Vmpp/V)	39.31	36.56	39.46	36.70	39.61	36.84	39.76	36.98	39.91	37.12
Maximum Power Current(Impp/A)	13.61	11.05	13.68	11.11	13.76	11.17	13.83	11.23	13.91	11.29
Open Circuit Voltage(Voc/V)	47.13	44.64	47.28	44.78	47.43	44.92	47.58	45.06	47.73	45.20
Short Circuit Current(Isc/A)	14.38	11.68	14.45	11.74	14.52	11.80	14.59	11.86	14.66	11.92
Module efficiency(%)	22.5%		22.7%		23.0%		23.2%		23.4%
Power Tolerance (W)	0~+5		0~+5		0~+5		0~+5		0~+5

BIFACIAL OUTPUT-REARSIDE POWER GAIN

5%	Maximum Power(Pmax)	562	567	572	578	583
5%	Module Efficiency STC (%)	23.7%	23.9%	24.1%	24.3%	24.6%
15%	Maximum Power(Pmax)	615	621	627	633	638
15%	Module Efficiency STC (%)	25.9%	26.2%	26.4%	26.7%	26.9%
25%	Maximum Power(Pmax)	669	675	681	688	694
25%	Module Efficiency STC (%)	28.2%	28.4%	28.7%	29.0%	29.2%

NMOT Temperature	45℃±2℃
Temprature Coefficient (Pmax)	-0.29%/℃
Temprature Coefficient (Voc)	-0.25%/℃
Temprature Coefficient (Isc)	0.045%/℃

Product Certification

NUUKO's products undergo strict quality inspections and comply with international standards. Certified by TÜV, DEKRA, UL, CE, IEC, CB, and IECEE, they also hold multiple patents and software copyrights.
